A brief introduction into Rancher, rke and explanation of Rancher specific terms with. Also directing you to the right resources. Based on my experience running Rancher Management Cluster and Rancher User Cluster on AWS EC2.
Rancher is a Kubernetes distribution build by Rancher Labs. There are some others like OpenShift from Red Hat with different features.
The distribution will run Kubernetes opinionated so you do not have to think of every detail.
Kubernetes does not come with a user management system. You could implement this on your own or just pick a distribution that has done all the work for you. Rancher comes with different authentication providers like GitHub, Azure AD and others. It is baked in. Just configure the authentication in Rancher, OpenShift or your Kubernetes distribution of choice and that is it.
Since it is opinionated, it may not fit your use case. Maybe you just need to dig a little deeper into the configuration options that depends on your needs.
Features Rancher will give you:
- User management, since Kubernetes does not have user management backed in
- A neat web interface to browse your clusters (yes, I mean several clusters!)
- Provision to major cloud providers (AWS, Google, Azure), bare metal, VMware vSphere etc.
- Kubernetes Cluster backups, upgrades, etc.
- One place to manage a lot
Listing all features of Rancher does not make sense here.
I just want you to know, that all lot is taken care of and that is the real reason to choose a Kubernetes distribution. This is basic and important stuff which you would need to implement by yourself. Pick your flavour and go with it like Linux distributions ?.
rke — Rancher Kubernetes Engine
Rancher2 is the shiny web interface and API everybody talks about. rke is the Kubernetes installer that you used to create Kubernetes clusters with when using Rancher.
It is rke which does the magic in Rancher. Rancher is packed with a certain version of rke. If you just want a Kubernetes Cluster to play with you can use several tools like:
rke is just another method to install and maintain your Kubernetes clusters in the Rancher opinionated way. There are a lot of configuration options. Check the rke docs for more information.
rke will give you a Kubernetes cluster to work with but not the Rancher web interface! This is somewhat confusing when you just start.
You can always see which Rancher version uses which rke version and therefore the support of the Kubernetes version in the rancher/rancher repository
Here you can see that rancher v2.2.11 uses rke v0.2.10 and supports up to these Kubernetes version:
A good overview for support and all the versions about Rancher can be found in their docs: Rancher Support Matrix
Rancher itself is the Rancher API and web interface which you often see on the internet when someone is referring to Rancher.
Rancher will run on top of your Kubernetes cluster created by rke. You can deploy Rancher via helm to that first rke cluster you created.
Here is the Rancher Helm Chart and the respective documentation on the Rancher website Install Rancher on the Kubernetes Cluster
So now you have a Kubernetes cluster with the Rancher 2 helm chart deployed on it. This Cluster should not be used as a Cluster for workloads. Since Rancher comes with rke you can now deploy as many clusters as you like to what location you like.
Rancher Management Cluster and User Cluster Example
Rancher/rke will not take care of your general AWS infrastructure like networking. This needs to be taken care of by yourself. I would recommend going with Terraform but AWS Cloudformation and the AWS Console will work as well.
The first thing you need is a network and nodes to install a Kubernetes cluster with rke. It would look like Figure 1:
A lot is missing like Internet Gateways, NAT Gateways, routing tables, routes and you could use an Application Load Balancer instead of the Network Load Balancer. But you get the idea.
Next, you would need to install Rancher to that Kubernetes cluster which is running on the 3 Rancher nodes. After some DNS configuration and certificates, you have a Rancher 2 web interface and API ready to go.
Easy right? Yeah. I know it is a lot of work. So let´s go on.
Now you can use the Rancher2 web interface to create your cluster right?
We first need another VPC to deploy the Rancher user cluster into. It is mostly the same setup as before but you need a VPC Perring (VPC Gateway is also possible) and you do not need to place EC2 nodes into the cluster. That will be taken care of Rancher.
Why do you need the peering? Rancher will ssh into each node and will do the provisioning for each Kubernetes node. Also, the created Kubernetes cluster will ping back to Rancher for health checks.
To create the actual user cluster you need to know how Rancher will create those. For that I will explain briefly what Rancher resources you need for the user cluster:
||rancher kubernetes engine. A Kubernetes installer in the Rancher way.|
||Rancher API and web interface.|
||Credentials to your provider (AWS, Google, Azure, etc.).|
||Definition of Node. Networking, Instance Type, Image, etc.|
||Mapping between Node Role and Node Template when creating a User Cluster.|
||Worker, etcd and Control Plane roles for Kubernetes|
||The Cluster created for your actual workload|
Cloud Credentials is just an AWS Access Key and Access Secret.
Do not use your user bound AWS credentials!
What will happen, when you deploy your Kubernetes Cluster with the credentials from a user and they leave the company?
- You will deactivate the AWS account because of offboarding
- Suddenly the cluster does not have proper credentials to interact with the AWS API anymore
- Finding out will take you some time and can have bad effects like nodes not coming up in AWS
Why do I know that? It is called experience ;-)
Node Templates are just what it says. You define values like:
- EC2 instance type
- ssh user
As you can see you need a Node Template for every availability zone since subnet in an AWS VPC is bound to an availability zone.
You also can use different EC2 instance types for Kubernetes Worker, etcd and control plane.
If you are testing out the provisioning and you encounter errors, check that the instance itself is not too small. I did run into it myself and could not figure out what was wrong. Increasing the EC2 instance type to a more performant machine did resolve that issue.
Kubernetes Cluster with Node Pools
A Kubernetes cluster in Rancher is made of Node Pools. The Node Pool is just a mapping between the Node Templates and the role in the cluster.
The role can be one of the following:
- Worker (will run your workload)
- etcd (Database for Kubernetes)
- control Plane (Kubernetes API)
Then you can configure the cluster itself with the right Cloud Provider. This will allow you to use the
serviceType LoadBalancer and AWS or other vendors will spawn a Load Balancer for your particular service.
Also, you can configure your network driver, snapshots and much more.
Rancher Terraform Provider
Rancher Labs is also providing an official Rancher2 Terraform Provider. You can create most resources specific to Rancher with that provider. Now you can automate everything with Terraform. From creating the network in AWS up to the cluster in Rancher.
Rancher2 Terraform Provider on the Terraform Website:
Rancher2 Terraform Provider source at GitHub :
rke Terraform Provider
There was a Terraform provider made by Kazumichi Yamamoto which I have used in version v0.14.1 to automate the creation of the Rancher management cluster. But I think Rancher has taken over the development of that project and the repository moved to the rancher organization.
Rancher Labs is pretty fast in developing these tools. It will take some time and then the Terraform rke provider will move to the official Terraform providers organization.
Until then, you have to download the provider by yourself at rancher-terraform-provider-rke. Only official HashiCorp providers listed here in the terraform-providers GitHub organization will be downloaded for you when running
Kubernetes itself already is a lot to learn. Put Rancher specific terms to that pile you have even more material to go through. We only did scratch the surface. For this to build you anyway need to learn AWS basics, Kubernetes basics and Rancher basics.
I hope that helped to understand Rancher running on AWS a little bit better.
